| Part Number | 3592109 |
| Previous versions | 2837303, 2843653, 3537886, 3537887, 3537888, 3537889, 3538249, 3538308, 3591365, 3592110, 3592110H, 3592111, 3592112, 3592113, 3802848 |
| OE number | 3802908, 380290800, 3802908NX, 3802908RX, J592109, J592110, J592111, J592112, J592113, J802908, JC537886, JR802908 |
| Description | Fits For Case-New Holland (CNH), Truck ELITE |
| CHRA | 3593410 (3580919, 3593410H, 4032115, 4032374, 3580234, 4027211)(1153030900, 1000020141) |
| Turbo Model | HX30, HX30-Q6819A/B06JX33 |
| Power | 90 HP |
| Engine | 4BTA |
| Engine Manufacturer | Fits For Cummins |
| Angle α (compressor housing) | 201° |
| Angle β (turbine housing) | 360° |
| Bearing Housing | 4030799 (3539227)(Oil Cooled)(1153030450, 1900011237) |
| Turbine Wheel | 3539805 (Ind. 65.07 mm, Exd. 52.01 mm, Trm 11, 12 Blades)(1153035436, 1100016201) |
| Comp. Wheel | 3599693 (Ind. 40. mm, Exd. 69.01 mm, Trm 9.65, 6+6 Blades, Superback)(1153030400, 1200016426) |
| Back plate | 3530923 (1800016009) |
| Heat shield Number | 3519304 (1153030340, 2030016049) |
| Repair Kit | 3575205 (1153030750, 5000020029) |
| Turbine Housing | 3537955 |
| Compressor Cover | 3539806 |
| Manufacturer | Aftermarket Parts |
Applications
Fits For 1998- Cummins Truck Elite with 4BTA Engine
BeeSpareParts
3592109 3802908 Turbocharger HX30 Turbo for Cummins 4BT 4BTA 3.9L Engine Trucks
- Regular price
- $ 468
| Part Number | 3592109 |
| Previous versions | 2837303, 2843653, 3537886, 3537887, 3537888, 3537889, 3538249, 3538308, 3591365, 3592110, 3592110H, 3592111, 3592112, 3592113, 3802848 |
| OE number | 3802908, 380290800, 3802908NX, 3802908RX, J592109, J592110, J592111, J592112, J592113, J802908, JC537886, JR802908 |
| Description | Fits For Case-New Holland (CNH), Truck ELITE |
| CHRA | 3593410 (3580919, 3593410H, 4032115, 4032374, 3580234, 4027211)(1153030900, 1000020141) |
| Turbo Model | HX30, HX30-Q6819A/B06JX33 |
| Power | 90 HP |
| Engine | 4BTA |
| Engine Manufacturer | Fits For Cummins |
| Angle α (compressor housing) | 201° |
| Angle β (turbine housing) | 360° |
| Bearing Housing | 4030799 (3539227)(Oil Cooled)(1153030450, 1900011237) |
| Turbine Wheel | 3539805 (Ind. 65.07 mm, Exd. 52.01 mm, Trm 11, 12 Blades)(1153035436, 1100016201) |
| Comp. Wheel | 3599693 (Ind. 40. mm, Exd. 69.01 mm, Trm 9.65, 6+6 Blades, Superback)(1153030400, 1200016426) |
| Back plate | 3530923 (1800016009) |
| Heat shield Number | 3519304 (1153030340, 2030016049) |
| Repair Kit | 3575205 (1153030750, 5000020029) |
| Turbine Housing | 3537955 |
| Compressor Cover | 3539806 |
| Manufacturer | Aftermarket Parts |
Applications
Fits For 1998- Cummins Truck Elite with 4BTA Engine
