Filter and sort
Electrical Parts
-
Vendor: Bobcat
New Starter Fits Bobcat Kubota 6676957 6685190 DSL6676957 TM0A28901 41040014 22306MD
Regular price $ 249 -
Vendor: Perkins
New 24V 10T CW Starter Motor Fits Caterpillar Loader Perkins Engine 2873K406
Regular price $ 359 -
Vendor: Kubota
12V 9T Starter 15852-63012 19837-63010 19837-63012 19837-63014 for Kubota Diesel Generator 5.5KVA Z482
Regular price $ 169 -
Vendor: Kubota
12V Starter 6A320-59210 Fit D722 D905 D1005 D1105 D1305 DF1005 Engine
Regular price $ 189 -
Vendor: Kubota
12V 9T 2.0KW 1K371-63010 Starter Fit For Kubota V2203 V2403 Engine
Regular price $ 239 -
Vendor: Kubota
12V Starter 028000-9030 028000-9031 028000-9032 fits for Kubota Engine 1P
Regular price $ 189 -
Vendor: Genie
23456GT 23456 STARTER ASSY For Genie GS-2668 RT GS-3268 RT Z-34/22 IC Z-45/22 MP
Regular price $ 209 -
Vendor: Kubota
19837-63010 12 Volt Starter Made Fits Kubota T1600H T1600HG Mower KH007H Excavator
Regular price $ 199 -
Vendor: Kubota
15425-63010 New Starter Fits Kubota Tractor Models R510 R520 SL4625 +
Regular price $ 189 -
Vendor: Kubota
Starter 1G023-63010 1G023-63011 67980-31151 for Kubota D722 D782 Engine
Regular price $ 189 -
Vendor: Kubota
Buy Starter M003T33481 For KUBOTA TRACTOR 19837-6301-1 18162 0.8kw 12V
Regular price $ 189 -
Vendor: ISUZU
9T Starter Motor for Isuzu Engine C240 2.4L Diesel 8-97112-865-2
Regular price $ 198
What are the electrical parts?
The electrical system has three main functions. One is to power the starter motor through the battery, causing the starter motor to run and complete the initial stage of the stroke work through the crankshaft connecting rod structure, and exit the next working system after the engine is started, so this part is sometimes called the engine's The main component of the starting system is the starter motor; the second is to ensure the normal operation of the engine during work, ensuring normal oil supply, normal air intake, and starting protection devices when encountering high temperatures and high pressures. The main components include various sensors and switches. Third, during operation, the charger is driven by the engine to charge the battery and ensure that the battery is fully charged. The main component is the charger.
The electrical system can be classified according to the speed control system of the engine. The electrical system of the machine control is relatively simple, including only the starter, charger, and switch with sensor function. Of course, some assembly plants may have additional wiring in the control box of the unit. , a sensor is installed in the engine for control; in addition to the mechanical starter and charger, the ESC also has an electronic speed regulator and actuator; while the EFI/electronic control is more complex, and its main features are various There are many sensors and they are controlled by a computer board.
1. Battery
The battery is generally not a product that comes with the engine, but is selected, tested and matched by the assembler. The usual voltage is 12V or 24V, and its main function is to power the starter motor, ECM and other electrical equipment. Under normal circumstances, when the engine is running once, the battery is fully charged, because although the battery is discharged in the early stage, it will be fully charged again during the engine running process.
2. Starting motor
The essence of a starter motor is an electric motor. The principle is the magnetic effect of current, which generates a magnetic field through energization and promotes the rotation of the starter. The starter is installed on the side of the timing gear. When starting, the probe of the starter stretches out, contacts the timing gear box gear, and pushes the gear to rotate. After reaching a certain speed, usually 250-300 rpm, the probe It will retract. At this time, the engine can run normally and the work of the starter motor is completed.
An introduction to the main systems of the engine - Youjia
3. Charger
It is also called an alternator, so it is essentially a small generator based on the principle of electromagnetic induction. Driven by the engine, the coil cuts the magnetic induction lines to generate current and supplies it to the battery. The gear of the charger is connected to the crankshaft gear through a belt, and its power is also provided through the crankshaft. The charger is equivalent to a microcosm of a diesel generator set and usually includes excitation windings, etc. We will discuss this later when we introduce the electric ball.
An introduction to the main systems of the engine - Youjia
4. Sensors and switches
Sensors and switches are electrical devices and serve a similar purpose. Sensors and switches feedback information to the computer board or controller through signals, so that the computer board or controller can perform corresponding actions according to the corresponding program. The difference is that the sensor generates pulse signals and transmits information to the control center continuously, while the switch has a threshold, and it is energized only when it exceeds or falls below the threshold and feeds back to the control center. Sensors usually include temperature sensors, pressure sensors, rotational speed sensors, etc., and switches are mainly temperature switches and pressure switches.
