Filter and sort
Electrical Parts
-
Vendor: ISUZU
12V 6 Pins Glow Plug Relay 129901-77960 for Yanmar Isuzu C240 Engine
Regular price $ 78 -
Vendor: Hitachi
Buy Relay Glow Plug 8-94248-1610 12V for Isuzu Hitachi ZAXIS27U ZAXIS50U ZAXIS40U 8942481610
Regular price $ 15 -
Vendor: Yanmar
Glow Plug Relay 119650-77910 119650-77911 for Yanmar NGK G71Su John Deere Cub Cadet
Regular price $ 19 -
Vendor: Yanmar
Glow Plug Safe Relay 12V 119650-77910 119650-77911 for Yanmar Engine 4TNV94 Excavator Hyundai R50 R60 Daewoo DH60-7 Volvo EC55BLC
Regular price $ 19 -
Vendor: Caterpillar
E320C E320D E320B Excavator Heater Relay Switch Magnetic Relay 1251302 125-1302
Regular price $ 65 -
Vendor: Others
Pre-heater Relay Switch 28620-1420A 182800-3330 S2862-01420 VH286201420 For SK200
Regular price $ 86 -
Vendor: Mitsubishi
1 pc New Parts relay heater ME220473 For Mitsubishi 4M50
Regular price $ 142 -
Vendor: Hyundai
Relay-Heater 21N8-42050 for CASE 1221F HyuRelay-Heater 21N8-42050 for CASE 1221F Hyundai HL940 Wheel Loaderndai HL940 Wheel Loader
Regular price $ 98 -
Vendor: SHANTUI
Fits For Shantui SD16/SD22/SD32 oil pressure sensor D2300-00000
Regular price $ 35 -
Vendor: Komatsu
Oil Water Separator Sensor 600-311-3721 for Komatsu Excavator PC200 PC210 PC230NHD PC240 PC290 PC300 PC300HD PC300LL PC350 PW140
Regular price $ 69 -
Vendor: Caterpillar
Water Separator sensor 178-2334 for Caterpillar 312D 313D 318D 319D 320C 320D 312D 322C 323D
Regular price $ 89 -
Vendor: Other
Fuel Injection Pump for Chinese 186F 186FA Generator
Regular price $ 22
What are the electrical parts?
The electrical system has three main functions. One is to power the starter motor through the battery, causing the starter motor to run and complete the initial stage of the stroke work through the crankshaft connecting rod structure, and exit the next working system after the engine is started, so this part is sometimes called the engine's The main component of the starting system is the starter motor; the second is to ensure the normal operation of the engine during work, ensuring normal oil supply, normal air intake, and starting protection devices when encountering high temperatures and high pressures. The main components include various sensors and switches. Third, during operation, the charger is driven by the engine to charge the battery and ensure that the battery is fully charged. The main component is the charger.
The electrical system can be classified according to the speed control system of the engine. The electrical system of the machine control is relatively simple, including only the starter, charger, and switch with sensor function. Of course, some assembly plants may have additional wiring in the control box of the unit. , a sensor is installed in the engine for control; in addition to the mechanical starter and charger, the ESC also has an electronic speed regulator and actuator; while the EFI/electronic control is more complex, and its main features are various There are many sensors and they are controlled by a computer board.
1. Battery
The battery is generally not a product that comes with the engine, but is selected, tested and matched by the assembler. The usual voltage is 12V or 24V, and its main function is to power the starter motor, ECM and other electrical equipment. Under normal circumstances, when the engine is running once, the battery is fully charged, because although the battery is discharged in the early stage, it will be fully charged again during the engine running process.
2. Starting motor
The essence of a starter motor is an electric motor. The principle is the magnetic effect of current, which generates a magnetic field through energization and promotes the rotation of the starter. The starter is installed on the side of the timing gear. When starting, the probe of the starter stretches out, contacts the timing gear box gear, and pushes the gear to rotate. After reaching a certain speed, usually 250-300 rpm, the probe It will retract. At this time, the engine can run normally and the work of the starter motor is completed.
An introduction to the main systems of the engine - Youjia
3. Charger
It is also called an alternator, so it is essentially a small generator based on the principle of electromagnetic induction. Driven by the engine, the coil cuts the magnetic induction lines to generate current and supplies it to the battery. The gear of the charger is connected to the crankshaft gear through a belt, and its power is also provided through the crankshaft. The charger is equivalent to a microcosm of a diesel generator set and usually includes excitation windings, etc. We will discuss this later when we introduce the electric ball.
An introduction to the main systems of the engine - Youjia
4. Sensors and switches
Sensors and switches are electrical devices and serve a similar purpose. Sensors and switches feedback information to the computer board or controller through signals, so that the computer board or controller can perform corresponding actions according to the corresponding program. The difference is that the sensor generates pulse signals and transmits information to the control center continuously, while the switch has a threshold, and it is energized only when it exceeds or falls below the threshold and feeds back to the control center. Sensors usually include temperature sensors, pressure sensors, rotational speed sensors, etc., and switches are mainly temperature switches and pressure switches.
